Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester

  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
  •  Coating Thickness Meter CM8829S /CM8829(F/NF/FN type) Car Paint Tester
Model No.︰CM-8829S
Brand Name︰LANTEK
Country of Origin︰China
Minimum Order︰1 pc
Share on:

 Total 42 Related Items
Prev3233343536Next

Product Description

Coating Thickness Meter CM-8829S (F/NF/FN type)



Coating thickness meter is widely used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.In industries of petroleum,shipbuilding,power station,and machine manufacturing.



With separate probes (please specify probe type, in built or separate while ordering)
Operating principle:
CM-8829F: F type(magnetic induction), measure the thickness of non-magnetic coating layers such as (aluminum,chrome,copper,ename1,rubber,paint) on magnetic substrate (steel, iron, alloy and magnetic steel)
CM-8829NF: NF type (eddy current), measure the thickness of non-conductive coating layers (ename1, rubber, paint, vanish, plastic anodic oxide layer) covered on non-ferrous substrate (aluminum, brass, zinc, tin and non-magnetic stainless steel)
CM-8829FN: F type & NF type

Specifications:
Measuring range: 0-1250um/0-50mil
Resolution: 0.1/1
Accuracy: +/-1-3%n or +/-2.5um
Min. measuring area: 6mm
Min. sample thickness: 0.3mm
Battery indicator: low battery indicator
Metric/ imperial: convertible
Power supply: 4x1.5V AAA(UM-4)battery
Auto power off
Operating conditions: 0-+45C(32F-104F), ≤90%RH
Dimensions: 126x65x27mm (5x2.6x1.07 inch)
Weight: 200g / 0.44lb (not including battery)
Optional accessories: other range 0-200um to 15000um

Coating Thickness Meter CM-8829 (F/NF/FN type)

Coating thickness meter is widely used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.In industries of petroleum,shipbuilding,power station,and machine manufacturing.


With separate probe (please specify probe type, in built or separate while ordering)
Operating principle:
CM-8829F: F type(magnetic induction), measure the thickness of non-magnetic coating layers such as (aluminum,chrome,copper,ename1,rubber,paint) on magnetic substrate (steel, iron, alloy and magnetic steel)
CM-8829NF: NF type (eddy current), measure the thickness of non-conductive coating layers (ename1, rubber, paint, vanish, plastic anodic oxide layer) covered on non-ferrous substrate (aluminum, brass, zinc, tin and non-magnetic stainless steel)
CM-8829FN: F type & NF typeSpecifications:
In built probes
Measuring range: 0-1250um/0-50mil
Resolution: 0.1/1
Accuracy: ±1-3%n or ±2.5um
Min. measuring area: 6mm
Min. sample thickness: 0.3mm
Battery indicator: low battery indicator
Metric/ imperial: convertible
Power supply: 4x1.5V AAA(UM-4)battery
Auto power off
Operating conditions: 0-+45C(32F-104F), ≤90%RH
Dimensions: 126x65x27mm (5x2.6x1.07 inch)
Weight: 115g / 0.25lb (not including battery)
Optional accessories: other range 0-200um to 15000um

about the shipment:we have spot goods in the warehouse and will deliver the goods 1 to 2 days after your payment ,about 3 to 7days to your delivery address.if you have any questions,please consult us

Our company has a history of 12 years, and has stores in AliExpress and Alibaba, the price here is the most favorable, welcome to consult us for more questions

Price Terms︰EXW shenzhen
Payment Terms︰TT/LC/WU/PAYPAL
Packing︰export carton
Lead Time︰2 days
