Tenmars TM195 3-AXIS EMF RF Radiation ElectroSmog Power Meter Tester
Features:
50MHz to 3.5GHz Frequency range.
For isotropic measurements of electromagnetic fields.
Non-directional (isotropic) measurement with
 three- channel measurement sensor.
High dynamic range due to three- channel digital results processing.
Configurable alarm threshold and memory function.
Easy & safety to use
Low battery detector
Over load indication.
Auto power off (adjustable from 0~99 min) with disable function.
Application:
High frequency (RF) electromagnetic wave field strength measurement.
Mobil phone base station antenna radiation power density measurement.
Wireless communication applications (CW, TDMA, GSM, DECT).RF power measurement for transmitters.
Wireless LAN (Wi-Fi) detection, installation.
Monitoring camera, wireless bug finder.
Cellular /Cordless phone radiation safety level.
Microwave oven leakage detection.
Personal living environment EMF safety.
Specification:
|
MODEL
|
TM-195 |
|
Measurement ranges
|
38mv to 11v/m
|
|
Display
|
3-3/4 digits maximum reading 3999
|
|
Frequency rangeÂ
|
50MHz ~ 3.5GHz
|
|
Measurement units
|
mV/m , V/m , µA/m , mA/m , µW/m2 ,
mW/m2 , µW/cm2
|
|
Display resolution
|
0.1mV/m, 0.1µA/m, 0.001µW/m2, 0.001µW/cm2
|
|
Manual data memory
|
Read storage:200 data sets.
|
|
Alarm function
|
Adjustable threshold with ON/ OFF
|
|
Memory Recall
|
Records Maximum & AVG
|
|
Calibration factor CAL
|
adjustable
|
|
Sampling Time
|
2.5 times per second.
|
|
Operating
Temperature and Humidity
|
Â
0 to 50CÂ ( 32F to 122F ). Max. 80% RH.
|
|
Power Supply
|
             9V battery(NEDA 1604 IEC 6F 22 JIS 006P)*1
|
|
Battery life
|
approx. 50 hr.
|
- Weight / Size: 180g / 195(L)*56(W)*38(H) mm
Features:
50MHz to 3.5GHz Frequency range.
For isotropic measurements of electromagnetic fields.
Non-directional (isotropic) measurement with
 three- channel measurement sensor.
High dynamic range due to three- channel digital results processing.
Configurable alarm threshold and memory function.
Easy & safety to use
Low battery detector
Over load indication.
Auto power off (adjustable from 0~99 min) with disable function.
Application:
High frequency (RF) electromagnetic wave field strength measurement.
Mobil phone base station antenna radiation power density measurement.
Wireless communication applications (CW, TDMA, GSM, DECT).RF power measurement for transmitters.
Wireless LAN (Wi-Fi) detection, installation.
Monitoring camera, wireless bug finder.
Cellular /Cordless phone radiation safety level.
Microwave oven leakage detection.
Personal living environment EMF safety.
Specification:
|
MODEL
|
TM-195 |
|
Measurement ranges
|
38mv to 11v/m
|
|
Display
|
3-3/4 digits maximum reading 3999
|
|
Frequency rangeÂ
|
50MHz ~ 3.5GHz
|
|
Measurement units
|
mV/m , V/m , µA/m , mA/m , µW/m2 ,
mW/m2 , µW/cm2
|
|
Display resolution
|
0.1mV/m, 0.1µA/m, 0.001µW/m2, 0.001µW/cm2
|
|
Manual data memory
|
Read storage:200 data sets.
|
|
Alarm function
|
Adjustable threshold with ON/ OFF
|
|
Memory Recall
|
Records Maximum & AVG
|
|
Calibration factor CAL
|
adjustable
|
|
Sampling Time
|
2.5 times per second.
|
|
Operating
Temperature and Humidity
|
Â
0 to 50CÂ ( 32F to 122F ). Max. 80% RH.
|
|
Power Supply
|
             9V battery(NEDA 1604 IEC 6F 22 JIS 006P)*1
|
|
Battery life
|
approx. 50 hr.
|
- Weight / Size: 180g / 195(L)*56(W)*38(H) mm
