HM6560 Leeb Hardness Tester Metals Durometer With 200 To 900 HLD Range Direct display of hardness scales HRB, HRC, HV, HB, HS,HL
* Palm size for narrow space.
* Test at any angle, even upside down.
* Direct display of hardness scales HRB, HRC, HV, HB, HS,HL.
* Large memory could store 50 groups including single measured value, impact direction, material and hardness scale etc.
* User recalibration function allowed.
* Manual or automatic shut down.
* Low battery indication.
* Use USB/RS-232 data output to connect with PC.(optional)
* Provide Bluetooth data output choice.(optional)
|
Material
|
Converting Ranges
|
|
HL
|
HRC
|
HRB
|
HB
|
HS
|
HV
|
|
30D²
|
10D²
|
|
Steel & Cast St.
|
300~900
|
20.0~68.0
|
38.4~99.5
|
80~647
|
|
32.5~99.5
|
80~940
|
|
C.W.Tool Steel
|
300~840
|
20.4~67.1
|
|
|
|
|
80~898
|
|
ST.Steel
|
300~800
|
19.6~62.4
|
46.5~101.7
|
85~655
|
|
|
80~802
|
|
Gray Cast Iron
|
360~650
|
|
|
93~334
|
|
|
|
|
Nodular Cast Iron
|
400~660
|
|
|
131~387
|
|
|
|
|
Cast Aluminum
|
174~560
|
|
|
|
20~159
|
|
|
|
Brass
|
200~550
|
|
13.5~95.3
|
|
40~173
|
|
|
|
Bronze
|
300~700
|
|
|
|
60~290
|
|
|
|
Copper
|
200~690
|
|
|
|
45~315
|
|
|
|
isplay
|
LCD
|
|
Materials
|
9 different common materials (Steel&Cast Steel,C.W.Tool Steel,Stainless Steel,
Gray Cast Iron,Nodular Cast Iron,Cast Aluminum,Brass,Bronze,Copper)
|
|
Measuring Range
|
200~900(HLD)
|
|
Accuracy
|
Display Error±0.8%
|
|
Repeatability
|
±0.8%
|
|
Conversion
|
HL-HRC-HRB-HB-HV-HSD
|
|
Memory
|
50Data Can Be Stored And Re-readable
|
|
Impact device
|
Probe D,Weight:75g
|
|
Storage Temperature
|
-30~60ºC
|
|
Operating Conditions
|
Temperature
|
-10~50ºC
|
|
Humidity
|
<90%RH
|
|
Power Supply
|
4X1.5V AAA(UM-4)Battery
|
|
Dimensions
|
120x62x30mm
|
|
Weight
|
164g(Not Including Batteries)
|
